Page 10 • Catalog 111
727-446-1656 • 1-800-446-1656 •
Model
Max
Volts
Max
Running
Inlet / Outlet
Dimensions (H x W x L)
GPM
Amps
PSI
JA 42755-0092
5.0
12 vdc
12
40
1
/
2
" Barb and Qest
4.34" x 6.13" x 9.88"
JA 42755-0094
5.0
24 vdc
6
40
1
/
2
" Barb and Qest
4.34" x 6.13" x 9.88"
1 to 5 GPM Variable Speed Aqua Jet Flow Master
The Flow Master 5.0 is a five chamber positive displacement diaphragm pump. The digital
controller adjusts water flow as the demand is increased or decreased while maintaining a
very smooth flow. The unique variable flow feature allows the pump to be mounted without
an accumulator tank and still maintain an even flow regardless if one or multiple taps are
being used.
Model
Max GPM
Volts
Fuse Size Max PSI Inlet /Outlet Dimensions (H x W x L)
JS 10-13329-103
5.2
12 vdc
15A
50
1
/
2
" Barb
4.49" x 8.22" x 9.4"
JS 10-13329-104
5.2
24 vdc
8A
50
1
/
2
" Barb
4.49" x 8.22" x 9.4"
1 to 8 GPM DUAL VSD VARIABLE SPEED system
The Dual VSD combines a smooth flowing VSD water system pump with a Par-Max water
system pump to provide up to 8 gpm when demand increases. The VSD pump with its variable
speed motor provides smooth even flow as needed for several outlets. If demand exceeds
the VSD’s normal operating range the Par-Max kicks in to add enough additional flow to
accommodate as many as seven outlets. An accumulator tank is NOT required!
Model
Max GPM
Volts
Max Amps
Inlet
Outlet
Dimensions (H x W x L)
JA 31765-0092
8
12 vdc
20
1
/
2
" FPT
1
/
2
" FPT
8.875" x 8.5" x 12
1
/
2
"
JA 31765-0094
8
24 vdc
10
1
/
2
" FPT
1
/
2
" FPT
8.875" x 8.5" x 12
1
/
2
"
variable flow water systems
JOHNSON
Flow Master
1 TO 5 GPM, “V-FLO” VSD VARIABLE FLOW SYSTEM
Jabsco’s new V-Flo, constant pressure water pump now feature new DiMOND technology
designed to automatically diagnose and monitor pump performance. V-Flo is powered by
a variable speed drive that delivers the exact flow needed while using 50% less power
consumption. The 5 chamber diaphragm design can be run dry without damage. Pump
comes with an in-line strainer and snap-fit port fittings.
SHURFLO
Smart Sensor
1 to 5 GPM, “Smart Sensor” Water Systems
The Extreme Series “Smart Sensor” pumps from Shurflo utilize a micro-controller to control
the speed of the motor to deliver a smooth variable flow to match the number of fixtures
in use at any time. All models have a corrosion resistant coated seamless motor shell and
protected electronics capable of handling the harsh marine environment. The 5901 series
comes with
1
/
2
" MPT quick connect ports. Also available:
1
/
2
" barb (94-615-01 straight/94-
615-00 elbow) and
3
/
4
" barb (94-615-04 straight/94-615-05 elbow). See page 64 for port
fitting options for the 4901 series and
for service parts on all models.
Model
Max GPM
Volts Max Amps Max PSI
Inlet/Outlet
Dimensions (H x W x L)
SF 4901-0211
4.0
12 vdc
9 amps
50
1
/
2
" Barb or
1
/
2
" Qest MPT
5.4" x 5.3" x 8.3"
SF 4901-1211
4.0
24 vdc
5 amps
50
1
/
2
" Barb or
1
/
2
" Qest MPT
5.4" x 5.3" x 8.3"
SF 5901-0211
5.0
12 vdc
12 amps
60
1
/
2
" Quest MPT
5.0" x 5.5" x 9.25"
SF 5901-1211
5.0
24 vdc
5 amps
60
1
/
2
" Quest MPT
5.0" x 5.5" x 9.25"
JABSCO
V-Flo 5.0
JABSCO
Dual-VSD
