Page 14 • Catalog 111
727-446-1656 • 1-800-446-1656 •
water systems
Universal
WHALE
Paragon Senior
groco
11 GPM PARAGON SENIOR FOR VESSELS 45' AND LARGER
TheParagon Senior is thepremierwater systemfor vessels 45 feet or larger. Eachpump is ignition
protected, supplied with a 30-50 psi waterproof pressure switch and features patented NoFlo™
dry run protection. Accessories include a pressure gauge, 1" strainer, and a solid-state dry tank
switch. An accumulator tank is required (see
. See
for service parts.
7 GPM PARAGON JUNIOR FOR UP TO 45' VESSELS
The Paragon Junior is an ideal water system for vessels up to 45 feet. Each pump is ignition
protected, supplied with a 20-40 psi waterproof pressure switch and features patented NOFLO™
dry run protection. Accessories include a pressure gauge,
3
/
4
" strainer, and a solid-state dry tank
switch. Available with one gallon accumulator tank or mounted on a 2 gallon tank.
Model
Max GPM
Volts
Breaker Size
Inlet & Outlet
Dimensions (H x W x L)
GC PSR-12V
11
12 vdc
50 amps
1" ID Hose
6.5" x 5" x 20.5"
GC PSR-24V
11
24 vdc
30 amps
1" ID Hose
6.5" x 5" x 20.5"
GC PSR-32V
11
32 vdc
20 amps
1" ID Hose
6.5" x 5" x 20.5"
GC PSR-115V
11
115 vdc
10 amps
1" ID Hose
6.5" x 5" x 20.5"
Model
Max GPM Volts Breaker Size Inlet & Outlet Dimensions (H x W x L)
Tank Option
GC PJR 12V
7
12 vdc
30 amps
3
/
4
" ID Hose
7" x 8.25" x 8.5"
GC PJR 24V
7
24 vdc
20 amps
3
/
4
" ID Hose
7" x 8.25" x 8.5"
GC PJR-A 12V
7
12 vdc
30 amps
3
/
4
" ID Hose
7" x 8.25" x 8.5"
1 gal accumulator
GC PJR-A 24V
7
24 vdc
20 amps
3
/
4
" ID Hose
7" x 8.25" x 8.5"
1 gal accumulator
GC PJR-B 12V
7
12 vdc
30 amps
3
/
4
" ID Hose 18.15" x 10.50" x 20.95" 2 gal accumulator
GC PJR-B 24V
7
24 vdc
20 amps
3
/
4
" ID Hose 18.15" x 10.50" x 20.95" 2 gal accumulator
2.2 to 4.75 GPM UNIVERSAL PUMP
The Whale Universal pump comes in 3 sizes for various flow and pressure needs. The pumps
feature quiet operation and smooth flow. They are self priming to 10 feet and can run dry
without damage. For extra protection and safety the wires and pressure switch are housed
internally. Inlet strainer and additional BSP fittings are included with pump.
johnson
Aqua-Jet
2.4 - 5.2 GPM AQUA-JET WATER SYSTEM PUMPS
The Aqua-Jet five chambered diaphragm pump design demonstrates dramatically lower noise
and water pulsation than traditional pump configurations. They come standard with a 40
psi switch and are available in 12 and 24 vdc in flows up to 5.2 gpm. An accumulator tank is
recommended (see
.
Model
Max GPM
Volts
Fuse Size
Inlet / Outlet
Dimensions (H x W x L)
JS 10-24604-103
2.4
12 vdc
10A
1
/
2
" &
3
/
8
" NPT,
1
/
2
" &
3
/
4
" Barb
4.3" x 3.5" x 8.02"
JS 10-24604-104
2.4
24 vdc
5A
1
/
2
" &
3
/
8
" NPT,
1
/
2
" &
3
/
4
" Barb
4.3" x 3.5" x 8.02"
JS 10-13395-103
3.5
12 vdc
10A
1
/
2
" &
3
/
8
" NPT,
1
/
2
" &
3
/
4
" Barb
4.6" x 5.14" x 9.3"
JS 10-13395-104
3.5
24 vdc
5A
1
/
2
" &
3
/
8
" NPT,
1
/
2
" &
3
/
4
" Barb
4.6" x 5.14" x 9.3"
JS 10-13406-103
4.0
12 vdc
10A
1
/
2
" &
3
/
8
" NPT,
1
/
2
" &
3
/
4
" Barb
4.3" x 5.10" x 9.5"
JS 10-13406-104
4.0
24 vdc
5A
1
/
2
" &
3
/
8
" NPT,
1
/
2
" &
3
/
4
" Barb
4.3" x 5.10" x 9.5"
JS 10-13406-107
5.2
12 vdc
15A
1
/
2
" &
3
/
8
" NPT,
1
/
2
" &
3
/
4
" Barb
4.3" x 5.10" x 9.5"
JS 10-13406-108
5.2
24 vdc
8A
1
/
2
" &
3
/
8
" NPT,
1
/
2
" &
3
/
4
" Barb
4.3" x 5.10" x 9.5"
Model
Max GPM
PSI
Volts
Fuse Size
Inlet/Outlet
Dimensions (H x W x L)
WH UF0812
2.2
15
12 vdc
5
1
/
2
" ID Hose
5" x 9" x 8
5
/
8
"
WH UF0815
2.2
45
12 vdc
5
1
/
2
" ID Hose
5" x 9" x 8
5
/
8
"
WH UF1212
3.2
15
12 vdc
5
1
/
2
" ID Hose
5" x 9" x 8
5
/
8
"
WH UF1214
3.2
30
12 vdc
8
1
/
2
" ID Hose
5" x 9" x 8
5
/
8
"
WH UF1215
3.2
45
12 vdc
8
1
/
2
" ID Hose
5" x 9" x 8
5
/
8
"
WH UF1225
3.2
45
24 vdc
4
1
/
2
" ID Hose
5" x 9" x 8
5
/
8
"
WH UF1815
4.75
45
12 vdc
12
3
/
4
" MPT
5" x 9" x 9
1
/
2
"
WH UF1825
4.75
45
24 vdc
8
3
/
4
" MPT
5" x 9" x 9
1
/
2
"
Paragon Junior
groco
