www.depcopump.com • 1-800-446-1656 • 727-446-1656
Catalog 111 • Page 17
mini water systems
shurflo / jabsco
flojet / JABSCO
1.0 - 2.3 GPM “MINI” WATER SYSTEM PUMPS
These “mini” water system pumps by Jabsco (4263X series) and Flojet (LF 122 series) are
extremely compact and energy efficient and are available with or without a 35 psi demand
pressure switch. The Flojet 02100 series is an economical low-flow water system with a 27 psi
demand pressure switch.
Max
Amps at
Inlet/
Pressure
Dimensions
Model
GPM
Volts
10 PSI
Outlet
Switch
(H x W x L)
FJ LF122-202A
1.0
12 vdc
1.9
3
/
8
" Barb
40 psi
2.3" x 3.5" x 6.4"
FJ LF122-002A
1.0
12 vdc
1.9
3
/
8
" Barb
None
2.3" x 3.5" x 6.4"
JA 42630-2900
1.1
12 vdc
1.9
3
/
8
" Barb
35 psi
2.3" x 3.5" x 6.4"
JA 42631-2900
1.1
12 vdc
1.9
3
/
8
" Barb
None
2.3" x 3.5" x 6.4"
FJ 02100-12
2.3
12 vdc
2.5
3
/
8
" FPT and
1
/
2
" Barb
27 psi
3.75" x 3.25" x 8.2"
FJ 02100-740
2.3
24 vdc
1.5
3
/
8
" FPT
27 psi
3.75" x 3.25" x 8.2"
1.0 GPM WATER SYSTEM PUMP AND FAUCET
This is an economical answer to running water at the turn of a switch. The pump is quiet, easy
to install, draws only 1.6 amps, and moves 1 gpm at 7 foot of head. The optional faucet has
a stainless steel swing spout, easy to clean white plastic base and built-in switch to operate
the pump. Both pump and faucet have
3
/
8
" hose connections. The centrifugal pump is not
self-priming and must be mounted below the water level or tank. Pump will operate with
fresh or salt water.
Model
Max GPM
Volts
Max Amps
Inlet / Outlet
Description
JA 42510-0000
1.0
12 vdc
1.6
3
/
8
" Barb
Pump only
JA 42530-0000
1.0
12 vdc
1.6
3
/
8
" Barb
Pump with faucet
SF 94-009-10
—
—
—
3
/
8
" Barb
Faucet only
SF 94-009-20
1.0
12 vdc
3.0
3
/
8
" Barb
Pump with faucet
1.85 TO 4.0 GPM HAND AND FOOT OPERATED PUMPS
The foot operated Gusher Galley MK3 (model number WH GP0550B) is a smoothly operating
double action diaphragm pump that can mount behind or on a bulkhead or directly on the floor.
The Whale WH GP1309 mounts neatly into the floor. When not in use the plunger locks down
flush with the floor. A simple twist releases the plunger for use.
Model
Brand
Max GPM
Port Size
Description
WH GP1309
Whale
1.85
1
/
2
" Barb
Flush floor mount foot operated pump
WH GP0550B
Whale
4.0
1
/
2
" Barb
Foot operated “Gusher Galley MK3”
Manual Water Systems
Whale
115 vac and 12 vdc bottled water dispenser
This system is ideal for automatically supplying bottled water to a refrigerator ice/water
dispenser and/or a water tap. It comes complete with a demand water pump, 20 feet of
1/4” discharge tube, suction tube with universal cap for a 5 gallon jug, and float switch for
automatic shutoff when the bottle is empty. There are two voltages (12 vdc and 115 vac).
Model
Volts
Included Accessories
FJ BW1000A
115 vac
20' of
1
/
4
discharge tube, suction tube and cap
FJ BW3000A
12 vdc
20' of
1
/
4
discharge tube, suction tube and cap
“Mini” Water Systems
bottled water
dispenser
