Catalog 111 • Page 57
tank management
jabsco
groco
GROCO HOLDING TANK WITH SWEETTANK™
Groco’s ZDS series is a self-contained Type-III waste management system that receives, holds,
deodorizes, and discharges water from one or more onboard toilets. Operation is efficient (17
gpm macerator pump is inside the holding tank) and reliable with state of the art touch-pad
control. The ZDS also includes SweetTank™which keeps the tank odor-free at all times, without
chemicals or filters. The ZDS system is available in many shapes and sizes.
WHALE GRAY WATER TANK WITH GULPER PUMP SYSTEM,
12 AND 24 VDC
This sump/pump combo allows you to plumb all gray water hoses to one location. Eight inlet
ports, each with two different dimensions permit a variety of hose sizes to be connected
reducing the number of thru hull fittings needed. Clear lid fits flush on top of the tank for
easy inspection. Sump/pump combo includes an automatic float switch that activates aGulper
pump. The tank can be mated with either a Gulper 220 (BP1552 or BP1554) or a Gulper 220
high flow model (BP3552B or BP 3554B). Gray waste tank only is part number GW0810.
johnson
whale
JOHNSON GRAY WATER TANK
The gray water tank is designed to be used as a collection tank for waste water from showers,
sinks, dishwashingmachineswith various inlet andoutlet port sizes.The tank includes a Johnson
Ultima switch for automatic operation and is easy to connect to any 12 or 24 vdc pump up to
20 amps. The tank is prepared for the Johnson Viking Power 16 (10-13350 Series pump), with
pre-drilled holes for the pump. The gray water tank model number is 09-13384.
DIGITAL HOLDING TANK MANAGEMENT SYSTEM
The easy to install new digital holding tank management system offers a full range of user
convenient features to monitor and evacuate waste. External sensors provide fast and
accurate level sensing eliminating the possibility of clogging. The easy to read touch pad
has an illuminated level indicator showing 8 level increments to full. The kits make it easy
to install a pump and level indicator system on an existing tank. The kits come in 12 or 24
vdc and can be supplied with or without pump.
Model
Volts
Description
JA 38210-0012
12
Sensor, Display and Control System
JA 38210-0024
24
Sensor, Display and Control System
JA 38220-0012
12
Sensor, Display and Control system with 18590 Pump included
JA 38220-0024
24
Sensor, Display and Control system with 18590 Pump included
JA 38230-0012
12
Sensor, Display and Control system with 50890 Pump included
JA 38230-0024
24
Sensor, Display and Control system with 50890 Pump included
ZDS Series
382XX-Series
Model
Description
Dimensions
JS 09-13384
Gray Water Tank
7.3" x 11" x 13.4"
Model
Description
Dimensions
WH GW0810
2.2 gal Gray Waste Tank only
6.56" x 10.25" x 13.75"
WH GW1610
4.4 gal Gray Waste Tank only
6.56" x 10.25" x 24.6"
Model
Volts
Description
Dimensions
GC ZDS-10
12 or 24 vdc
10 gal Gray Waste System
17" x 14" x 13.7"
GC ZDS-15
12 or 24 vdc
15 gal Gray Waste System
24" x 14" x 13.7"
GC ZDS-20
12 or 24 vdc
20 gal Gray Waste System
28.3" x 11.5" x 15"
GC ZDS-30
12 or 24 vdc
30 gal Gray Waste System
28" x 23" x 15"
Viking Series
GW Series
